The Multi Stage pump arranges multi stages which have several impellers on a same axis, providing low noise and low vibration. Based on its superior design and manufacturing technology, it satisfies a variety of requirements from our customers.



  • Application
  • Boiler Feed
  • Mine Dewatering
  • Chemical Process
  • Other high Pressure services

  • Features
  • Centerline supported and compact design
  • High efficiency and reliability
  • Design flexibility allows wide range of liquids to be handled
  • All components have been designed for maximum parts interchangeability
  • Low NPSH performance

  • Specification & Service Rages
  • Capacities : To 720 m/hr
  • Heads : To 2,500 m
  • Design pressures : 245kgf/㎠G(3,480 PSIG)
  • Impeller type : Enclosed
  • Temperature range : ~ 250C




  • Application
  • Boiler Feed
  • Mine Dewatering
  • Chemical Process
  • Other high Pressure services

  • Features
  • Centerline supported and compact design
  • High efficiency and reliability
  • Design flexibility allows wide range of liquids to be handled
  • All components have been designed for maximum parts interchangeability
  • Low NPSH performance

  • Specification & Service Rages
  • Capacities : To 720 m/hr
  • Heads : To 2,500 m
  • Design pressures : 245kgf/cmG(3,480 PSIG)
  • Impeller type : Enclosed
  • Temperature range : ~ 250C




  • Application
  • Petroleum refineries
  • Petrochemical industries
  • Other chemical industries
  • Boiler Feed
  • Descaling
  • Mine Dewatering
  • Sea water Injection for Oil-wells

  • Features
  • Centerline support and heavy duty design
  • Axially split, permits removal of top half of case
  • Full compliance with API610 specifications
  • nd balance piston or impeller arrangement
  • Design flexibility allows wide range of liquids to be handled
  • Low NPSH performance
  • All components have been designed for maximum parts interchangeability

  • Specification & Service Rages
  • Capacities : To 4,200 m/hr
  • Heads : To 1,500 m
  • Design pressures : 200kgf/cmG(2,845 PSIG)
  • Impeller type : Enclosed
  • Temperature range : ~ 230C




  • Application
  • Petroleum refineries
  • Petrochemical industries
  • Other chemical industries
  • Boiler Feed
  • Descaling
  • Mine Dewatering
  • Sea water Injection for Oil-wells

  • Features
  • Centerline support and heavy duty design
  • Axially split, permits removal of top half of case
  • Full compliance with API610 specifications
  • Radial and axial Halance is assured by diffuser design and balance piston or impeller arrangement
  • Design flexibility allows wide range of liquids to be handled
  • Low NPSH performance
  • All components have been designed for maximum parts interchangeability

  • Specification & Service Rages
  • Capacities : To 4,200 m/hr
  • Heads : To 1,500 m
  • Design pressures : 200kgf/cmG(2,845 PSIG)
  • Impeller type : Enclosed
  • Temperature range : ~ 230C




  • Application
  • Petroleum Refineries
  • Petrochemical Industry
  • Other Chemical Industries
  • Boiler Feed
  • Mine Dewatering

  • Features
  • Centerline support and heavy duty design
  • Axially split, permits removal of top half of case
  • Full compliance with API610 specifications
  • Radial and axial Halance is assured by diffuser design and balance piston or impeller arrangement
  • Design flexibility allows wide range of liquids to be handled
  • Low NPSH performance
  • Compact installation and easy maintenance
  • All components have been designed for maximum parts interchangeability

  • Specification & Service Rages
  • Capacities : To 4,200 m/hr
  • Heads : To 1,500 m
  • Design pressures : 225kgf/㎠G(3,200 PSIG)
  • Impeller type : Enclosed
  • Temperature range : ~ 230C




  • Application
  • Petroleum Refineries
  • Petrochemical industries
  • Other Chemical Industries
  • Boiler Feed
  • Mine Dewatering

  • Features
  • Centerline supported and heavy duty design
  • Axially split, permits removal of top half of case
  • Full compliance with API682 specifications
  • Radial and axial balance is assured by diffuser design and balance piston or impeller arrangement
  • Flexibility of design handles wide range of liquids
  • Low NPSH performance
  • Small installation area and easy maintenance
  • All components have been designed for maximum parts interchangeability

  • Specification & Service Rages
  • Capacities : To 180 m/hr
  • Heads : To 1,500 m
  • Design pressures : 225kgf/cmG(3,200 PSIG)
  • Impeller type : Enclosed
  • Temperature range : ~ 230C




  • Application
  • Boiler Feed water
  • Processing water
  • City water and high pressure water

  • Features
  • High efficiency over a wide range
  • Highly reliable componets
  • Simple construction permits easy maintenance
  • Suitable for low NPSH operation
  • Compact and inexpensive

  • Specification & Service Rages
  • Capacities : To 720 m/hr
  • Heads : To 135 m
  • Design pressures : 24kgf/CmG(340 PSIG)
  • Impeller type : Open
  • Temperature range : -50c ~ 260c




  • Application
  • Water supply
  • Emergency fire
  • city water supply
  • Pressure service
  • Industrial water
  • Boiler feed water

  • Features
  • Featuring high efficiency by outstanding and simple design and manufacture in multistage turbine high pressure centrifugal pump
  • Paralleled axis force assures high efficiency and performance in high speed rotation
  • Static and dynamic balanced design allows less noise and low vibration
  • Presents comfort selection by standardization and seriesed

  • Specification & Service Rages
  • Capacities : To 500 m/hr
  • Heads : To 380 m
  • Design pressures : 10kgf/cmG(142 PSIG)
  • Impeller type : Enclosed
  • Temperature range : 0 ~ 90c
